Reflects sunlight outdoors
Out is an extremely durable, effective collection of exterior screens - woven with coated fiberglass yarns - making these screens ideal for outdoor use. Copaco offers a wide range of fabric and color options that ensure a perfect fit. Two new lines, made with the innovative Block fabrics, Lunar and Solar, provide perfectly blocking & transparency. Out screens are a decorative feature of countless home and offices around the world, giving energy savings and light transmission a new dimension.
Reflects sunlight outdoors
Reflects sunlight outdoors
Out is an extremely durable, effective collection of exterior screens - woven with coated fiberglass yarns - making these screens ideal for outdoor use. Copaco offers a wide range of fabric and color options that ensure a perfect fit. Two new lines, made with the innovative Block fabrics, Lunar and Solar, provide perfectly blocking & transparency. Out screens are a decorative feature of countless home and offices around the world, giving energy savings and light transmission a new dimension.
Innovations
Openness factor 10%
Widths
Product ref.
270 cm
010010 - charcoal | charcoal
- Available
Downloads
Certificates
To view the certificates, please login.
Technical info
General
Composition
Glassfibre 42% - PVC 58%
Openness factor
NBN EN 410
10.00%
Weight
NF EN 12127
490.00 g/m²
Thickness
ISO 5084
0.83 mm
Density
ISO 2286-3
Warp18.00 yarn/cm
Weft12.00 yarn/cm
Color fastness to artificial light
ISO 105 B02
>7
Color fastness to artificial weathering
ISO 105 B04
>7
Roll length
50 m
Cleaning
With soapy water
Confection
By heat, high frequency or ultrasonic welding
Fire classification
└Europe
UNE-EN 13501-1:2007
└France
NF P92-503
M1
└Italy
UNI 9177
Class 1
└Germany
DIN 4102
B1
└UK
BS 5867
C
└USA
NFPA 701
FR
Tear strength
ISO 4674-1 method 2
└Original
Warp9.60 daN
Weft7.60 daN
└After climatic chamber -30°C
Warp8.60 daN
Weft7.10 daN
└After climatic chamber +70°C
Warp8.80 daN
Weft7.00 daN
Elongation up to break
ISO 1421
└Original
Warp5.20 %
Weft4.90 %
└After colour fastness to artificial weathering
Warp5.80 %
Weft5.00 %
└After color fastness to artificial light
Warp6.70 %
Weft5.20 %
└After climatic chamber -30°C
Warp5.00 %
Weft4.80 %
└After climatic chamber +70°C
Warp4.80 %
Weft4.20 %
Breaking strength
ISO 1421
└Original
Warp312.00 daN/5cm
Weft200.00 daN/5cm
└After colour fastness to artificial weathering
Warp289.00 daN/5cm
Weft190.00 daN/5cm
└After color fastness to artificial light
Warp289.00 daN/5cm
Weft185.00 daN/5cm
└After climatic chamber -30°C
Warp271.00 daN/5cm
Weft174.00 daN/5cm
└After climatic chamber +70°C
Warp217.00 daN/5cm
Weft139.00 daN/5cm
Front - Interior
Visual properties
Tv = Visual light transmittance
6.10%
Tuv = UV transmittance
6.14%
Solar energetic properties
As = Solar absorptance
89.80%
Rs = Solar reflectance
4.10%
Ts = Solar transmittance
6.10%
Fabric + glazing: G-factor
Glazing A
G 0.76
Te 0.00
Qi 0.00
SC 0.00
Glazing B
G 0.71
Te 0.00
Qi 0.00
SC 0.00
Glazing C
G 0.57
Te 0.00
Qi 0.00
SC 0.00
Glazing D
G 0.31
Te 0.00
Qi 0.00
SC 0.00
- G = Total solar energy transmittance
- Te = Direct solar transmittance
- Qi = Secondary heat transfer factor
- SC = Shading coefficient
Visual comfort
Normal solar transmittance
Class 6
Glare control
Class 4
Very good effect
Privacy night
Class 4
Very good effect
Visual contact with the outside
Class 2
Moderate effect
Daylight utilisation
Class 0
Very little effect
Thermal comfort Qi-factor = Secondary heat transfer factor
Glazing A
Class 0
Very little effect
Glazing B
Class 0
Very little effect
Glazing C
Class 0
Very little effect
Glazing D
Class 0
Very little effect
- Class 0 = Very little effect
- Class 1 = Little effect
- Class 2 = Moderate effect
- Class 3 = Good effect
- Class 4 = Very good effect
Back - Interior
Visual properties
Tv = Visual light transmittance
6.10%
Tuv = UV transmittance
6.14%
Solar energetic properties
As = Solar absorptance
90.20%
Rs = Solar reflectance
3.70%
Ts = Solar transmittance
6.10%
Fabric + glazing: G-factor
Glazing A
G 0.76
Te 0.00
Qi 0.00
SC 0.00
Glazing B
G 0.71
Te 0.00
Qi 0.00
SC 0.00
Glazing C
G 0.57
Te 0.00
Qi 0.00
SC 0.00
Glazing D
G 0.31
Te 0.00
Qi 0.00
SC 0.00
- G = Total solar energy transmittance
- Te = Direct solar transmittance
- Qi = Secondary heat transfer factor
- SC = Shading coefficient
Visual comfort
Normal solar transmittance
Class 6
Glare control
Class 4
Very good effect
Privacy night
Class 4
Very good effect
Visual contact with the outside
Class 2
Moderate effect
Daylight utilisation
Class 0
Very little effect
Thermal comfort Qi-factor = Secondary heat transfer factor
Glazing A
Class 0
Very little effect
Glazing B
Class 0
Very little effect
Glazing C
Class 0
Very little effect
Glazing D
Class 0
Very little effect
- Class 0 = Very little effect
- Class 1 = Little effect
- Class 2 = Moderate effect
- Class 3 = Good effect
- Class 4 = Very good effect
Front - Exterior
Visual properties
Tv = Visual light transmittance
6.10%
Tuv = UV transmittance
6.14%
Solar energetic properties
As = Solar absorptance
89.80%
Rs = Solar reflectance
4.10%
Ts = Solar transmittance
6.10%
Fabric + glazing: G-factor
Glazing A
G 0.31
Te 0.00
Qi 0.00
SC 0.00
Glazing B
G 0.24
Te 0.00
Qi 0.00
SC 0.00
Glazing C
G 0.15
Te 0.00
Qi 0.00
SC 0.00
Glazing D
G 0.13
Te 0.00
Qi 0.00
SC 0.00
- G = Total solar energy transmittance
- Te = Direct solar transmittance
- Qi = Secondary heat transfer factor
- SC = Shading coefficient
Visual comfort
Normal solar transmittance
Class 6
Glare control
Class 4
Very good effect
Privacy night
Class 4
Very good effect
Visual contact with the outside
Class 2
Moderate effect
Daylight utilisation
Class 0
Very little effect
Thermal comfort Qi-factor = Secondary heat transfer factor
Glazing A
Class 0
Very little effect
Glazing B
Class 0
Very little effect
Glazing C
Class 0
Very little effect
Glazing D
Class 0
Very little effect
- Class 0 = Very little effect
- Class 1 = Little effect
- Class 2 = Moderate effect
- Class 3 = Good effect
- Class 4 = Very good effect
Back - Exterior
Visual properties
Tv = Visual light transmittance
6.10%
Tuv = UV transmittance
6.14%
Solar energetic properties
As = Solar absorptance
90.20%
Rs = Solar reflectance
3.70%
Ts = Solar transmittance
6.10%
Fabric + glazing: G-factor
Glazing A
G 0.31
Te 0.00
Qi 0.00
SC 0.00
Glazing B
G 0.24
Te 0.00
Qi 0.00
SC 0.00
Glazing C
G 0.15
Te 0.00
Qi 0.00
SC 0.00
Glazing D
G 0.13
Te 0.00
Qi 0.00
SC 0.00
- G = Total solar energy transmittance
- Te = Direct solar transmittance
- Qi = Secondary heat transfer factor
- SC = Shading coefficient
Visual comfort
Normal solar transmittance
Class 6
Glare control
Class 4
Very good effect
Privacy night
Class 4
Very good effect
Visual contact with the outside
Class 2
Moderate effect
Daylight utilisation
Class 0
Very little effect
Thermal comfort Qi-factor = Secondary heat transfer factor
Glazing A
Class 0
Very little effect
Glazing B
Class 0
Very little effect
Glazing C
Class 0
Very little effect
Glazing D
Class 0
Very little effect
- Class 0 = Very little effect
- Class 1 = Little effect
- Class 2 = Moderate effect
- Class 3 = Good effect
- Class 4 = Very good effect
