Technical info
General
Composition
Fibreglass 36% - PVC 64%
Openness factor
NBN EN 410
24.00%
Weight
NF EN 12127
245.00 g/m²
Thickness
ISO 5084
0.30 mm
Density
ISO 7211/2
Warp18.00 yarn/cm
Weft10.00 yarn/cm
Color fastness to artificial light
ISO 105 B02
> 7
Cleaning
With soapy water
Confection
By heat, high frequency or ultrasonic welding
Fire classification
└France
NF P92-503
M1
└Italy
UNI 9177
Class 1
└Germany
DIN 4102
└UK
BS 5867
C
└USA
NFPA 701
FR
Tear strength
ISO 4674-1 methode 2
└Original
Warp4.15 daN
Weft3.95 daN
└After climatic chamber -30°C
Warp4.30 daN
Weft4.15 daN
└After climatic chamber +70°C
Warp4.20 daN
Weft3.95 daN
Elongation up to break
ISO 1421
└Original
Warp3.80 %
Weft2.20 %
└After color fastness to artificial light
Warp3.50 %
Weft2.00 %
└After climatic chamber -30°C
Warp3.60 %
Weft1.90 %
└After climatic chamber +70°C
Warp3.70 %
Weft1.65 %
Breaking strength
ISO 1421
└Original
Warp120.00 daN/5cm
Weft80.00 daN/5cm
└After color fastness to artificial light
Warp110.00 daN/5cm
Weft73.00 daN/5cm
└After climatic chamber -30°C
Warp110.00 daN/5cm
Weft65.00 daN/5cm
└After climatic chamber +70°C
Warp105.00 daN/5cm
Weft52.00 daN/5cm
Front - Interior
Visual properties
Tv = Visual light transmittance
23.20%
Tuv = UV transmittance
21.90%
Solar energetic properties
As = Solar absorptance
61.20%
Rs = Solar reflectance
15.00%
Ts = Solar transmittance
23.80%
Fabric + glazing: G-factor
Glazing A
G 0.66
Te 0.00
Qi 0.00
SC 0.00
Glazing B
G 0.63
Te 0.00
Qi 0.00
SC 0.00
Glazing C
G 0.52
Te 0.00
Qi 0.00
SC 0.00
Glazing D
G 0.30
Te 0.00
Qi 0.00
SC 0.00
- G = Total solar energy transmittance
- Te = Direct solar transmittance
- Qi = Secondary heat transfer factor
- SC = Shading coefficient
Thermal comfort Qi-factor = Secondary heat transfer factor
Glazing A
Class 0
Very little effect
Glazing B
Class 0
Very little effect
Glazing C
Class 0
Very little effect
Glazing D
Class 0
Very little effect
- Class 0 = Very little effect
- Class 1 = Little effect
- Class 2 = Moderate effect
- Class 3 = Good effect
- Class 4 = Very good effect
Back - Interior
Visual properties
Tv = Visual light transmittance
23.20%
Tuv = UV transmittance
21.90%
Solar energetic properties
As = Solar absorptance
60.90%
Rs = Solar reflectance
15.30%
Ts = Solar transmittance
23.80%
Fabric + glazing: G-factor
Glazing A
G 0.66
Te 0.00
Qi 0.00
SC 0.00
Glazing B
G 0.63
Te 0.00
Qi 0.00
SC 0.00
Glazing C
G 0.52
Te 0.00
Qi 0.00
SC 0.00
Glazing D
G 0.30
Te 0.00
Qi 0.00
SC 0.00
- G = Total solar energy transmittance
- Te = Direct solar transmittance
- Qi = Secondary heat transfer factor
- SC = Shading coefficient
Thermal comfort Qi-factor = Secondary heat transfer factor
Glazing A
Class 0
Very little effect
Glazing B
Class 0
Very little effect
Glazing C
Class 0
Very little effect
Glazing D
Class 0
Very little effect
- Class 0 = Very little effect
- Class 1 = Little effect
- Class 2 = Moderate effect
- Class 3 = Good effect
- Class 4 = Very good effect
